EXINDA 12kW R290 Monoblock Air-to-Water Heat Pump
R290 RESIDENTIAL AIR-TO-WATER HEAT PUMP
The XDASH12C3 is a 12 kW R290 heat pump for a single-family house. It runs on the single-phase supply the house already has, so replacing the boiler does not mean rewiring. It heats, cools and prepares domestic hot water, and works with the radiators or underfloor heating already in place.
Core Specifications
| Model | XDASH12C3 |
| Nominal heating / cooling | 12 kW at A7/W35 / 7 kW at A35/W7 |
| Refrigerant / charge | R290 / 0.8 kg |
| Published ambient range | −25 to 43 °C |
| Heating / cooling leaving water | 35–60 °C / 7–27 °C |
| Power supply | 220–240 V / 50 Hz / 1 Ph |
| Compressor | DC inverter |
| MCA / MOP | 28 A / 35 A |
| Water connection / nominal flow | G1 in. / 2.0 m³/h |
| Sound | 61 / 57 / 38 dB(A), daytime max / rated / low (submittal) |
| Dimensions (L × W × H) | 1200 × 550 × 855 mm |
| Net weight | 105 kg |
| Cascade | Up to 8 units stated in submittal; confirm controller and hydraulic design |
| Controls interfaces | SG Ready; Modbus RS485 and dry-contact interfaces |
| Heat Pump KEYMARK | Registration 041-K114-03, issued by BRE Global (certification body 041) for the XDASH12C series (XDASH12C3A / 3B / 3C / 3A-S). Tested to EN 14511:2022, EN 14825:2022 and EN 12102-1:2022; valid to 6 September 2035. Certificate 041-K114-03 (PDF, BRE Global) · Heat Pump KEYMARK register. |
| MCS (UK) | Certificate MCS HP0403; MCS HP0403/09 for XDASH12C3A, series references MCS HP0403/09 – /12; MCS 007 Issue 6.1, BRE Global. MCS product listing. |
| BAFA (Germany) | Listed in the BAFA list of eligible heat pumps for the Bundesförderung für effiziente Gebäude (BEG), Anlagennummer 16020242. BAFA programme information. |
| ErP / Ecodesign | Regulations (EU) 813/2013 and 811/2013, tested to EN 14825:2022 by SGS-CSTC Standards Technical Services, Shunde, report GZEE260600281031 (29 June 2026). Seasonal space heating efficiency ηs 202 % at W35, class A+++ (SCOP 5.13); 143.0 % at W55, class A++ (SCOP 3.65). Average climate. |
| CE / EPREL | CE marked. EU product database record EPREL 2736155 for XDASH12C3A; Declaration of Conformity supplied with the technical documents. |
Heating Performance at Project Conditions
Heating capacity, power input and COP at the temperatures shown below.
| Outdoor condition | Leaving water | Maximum heating capacity | Input power | COP |
|---|---|---|---|---|
| A7 DB / 6 WB | 35 °C | 12.084 kW | 3.064 kW | 3.94 |
| A2 DB / 1 WB | 35 °C | 10.599 kW | 2.829 kW | 3.75 |
| A−7 DB / −8 WB | 35 °C | 7.951 kW | 2.865 kW | 2.78 |
| A−15 DB / −16 WB | 35 °C | 6.235 kW | 2.608 kW | 2.39 |
Technical Documents
R290 Heat Pump Selection Questions
Can I choose this model when the property has no three-phase supply?
Yes. This is a single-phase option. Have the installer compare the property's available electrical capacity with the protection requirements in the specification, alongside the building's heating demand.
If one unit does not cover the winter load, should I choose a larger model or a cascade?
Compare the alternatives at the same design condition. A larger unit may simplify the installation where the electrical supply permits it; a cascade adds units and hydraulic coordination. Also assess any existing supplementary heat before choosing the system arrangement.
